描述
| FWHM | Band 1: 20 nm Nominal, Band 2: 24 nm Nominal |
|---|---|
| Center Wavelength | 486 nm ± 4.0 nm, 564 nm ± 4.0 nm |
| † Transmission Band(s) | 478 to 494 nm > 90% T Average, 554 to 574 nm > 90% T Average |
| Blocking Level | OD6 |
| * Blocking Range(s) | OD6: 200 to 466.5 nm, 505.9 to 540.5 nm, 588 to 1150 nm |
| Dimensions | 25.0 mm Diameter |
| Substrate Type | Fused Silica |
| Filter Thickness | 2.0 mm |
| Assembly Type | Anodized Aluminum Ring |
| Assembly Thickness | 3.5 mm |
| Custom Sizing Available | yes |
| Main Fluorophore(s) | FITC, mCherry |
| Alternate Fluorophore(s) | 5-FAM, Alexa Fluor® 488, Alexa Fluor® 568, AsRed2, ATTO 488, ATTO 565, ATTO RHO101, ATTO RHO11, ATTO RHO12, ATTO RHO3B, ATTO Thio12, Azami Green, Azami Green (monomeric), BCECF@pH5.2, BCECF@pH5.5, BO-PRO-3, BOBO-3, BODIPY® FL, BODIPY® FL (IgG), BODIPY® TR-X, BODIPY® TR-X (Phallacidin), C-PC, Calcein, Calcein Red-Orange, CellTrace Calcein Red-Orange, CellTracker Red CMTPX, CF488A, CF570, CF583, Crystal Violet (glycerol), Cy®2, CyQUANT®, DHPE Texas Red®, DiO, DY-590, EGFP, Emerald, FlAsH, Fluo-3, Fluo-4, Fluorescein (0.1M NaOH), Fluorescein (IgG), Fluoro-Emerald, FluoSpheres® Red, FusionRed, HCS CellMask Green, HCS LipidTOX Green Neutral Lipid Stain, HCS LipidTOX Red Neutral Lipid Stain, HCS LipidTOX Red Phospholipidosis Detection Reagent, HiLyte Fluor 488, Katushka2S, KFP-Red, Lissamine Rhodamine, LIVE/DEAD® Fixable Green Dead Cell Stain, LysoTracker® Green, mApple, mHoneydew, MitoTracker® Green FM, MitoTracker® Red, mKate2, mPlum, mRFP1, mStrawberry, mWasabi, NBD, NBD-X, NeuroTrace® 500/525 Green Fluorescent Nissl Stain (RNA), Nile Red, Oregon Green® 488, PA-GFP (post-activation), PA-TagRFP, PicoGreen® dsDNA Quantitation Reagent, PromoFluor-488, PromoFluor-488 Premium, PromoFluor-568, PromoFluor-590, PromoFluor-594, PS-CFP2, ReAsH, Rhodamine 110, Rhodamine Green, Rhodamine Red-X, Rhodol Green, Spectrum Green, Spectrum Orange, Sulforhodamine 101, SYBR® Gold, SYBR® Green I, SYTO® 13, SYTO® 16, SYTO® RNASelect, SYTOX® Green, TagGFP, TagGFP2, TagRFP, tdTomato, TurboFP602, TurboGFP, WEGFP (post-activation), X-rhod-1, YO-PRO®-1, YOYO®-1, ZsGreen1 |
*Auxiliary blocking typical based on the displayed spectrum.
