1065-1 OD8

$5,033.00

Ultra-narrowband optical interference filter with a 1065 nm center wavelength (CWL), a 1 nm full-width at half-maximum (FWHM), and wide-range OD6 out-of-band blocking from 200 nm to 1200 nm. This is a multi-cavity filter with steep edges, a flat top, and transmission that is greater than 90% at 1065 nm. This ultra-narrowband filter is coated on a 2 mm thick Borofloat® substrate and mounted in a 50.8 mm (+0/-0.4 mm) diameter, 3.5 mm (± 0.1 mm) thick anodized aluminum ring. Alluxa ultra-narrow bandpass filters have the highest transmission and narrowest bandwidths currently available. And because they are hard-coated using our innovative SIRRUS plasma deposition process, all Alluxa optical filters are highly durable and resistant to laser damage. Contact us for custom sizing options.

SKU： 7686 分类：

描述

Angle of Incidence  0 Degrees
Filter Design Multi-Cavity
Center Wavelength  1065 nm Nominal
FWHM  < 1.2 nm
† Transmission Band(s)  1065 nm > 90% T Absolute
Blocking Level  OD8
* Blocking Range(s)  OD8 (By Design): 354.72 nm, 532.08 nm; OD6: 1086 to 1200 nm, 200 to 1042 nm
Dimensions 50.6 mm Diameter
Filter Thickness 2.0 mm
Substrate Type  Borofloat®
Assembly Type Anodized Aluminum Ring
Assembly Thickness 3.5 mm
Custom Sizing Available yes

*Auxiliary blocking typical based on the displayed spectrum.

†For filters with less than 1nm bandwidth, measurement limitations may result in slight transmission variation. Please contact us for more information.
